Operational Features:

• Both the rotors are placed on individual well supported shafts.
• These rotors are rotated by timing gears fitted in an in-built gearbox.
• There is no contact between lobes due to timing gears.
• These rotors perform liquid tight fit operation with less noise and nearly vibration free flow.
• The liquid never passes through the gap between two lobes and it travels in the space between casing and lobes.
• The operation and delivery of pumping fluid is smooth with no churning effect.

Installation Features:

• These pumps can either be horizontal or vertical foot mounted as per requirement.
• Can be provided with geared motor or with built – in speed reducer.
• The sealing options provided in this series are either mechanical seal or lip seal, as per the application and requirement.
• The standard direction of rotation is anti-clockwise from the pump shaft end with left IN and right OUT configuration.
• The number of lobes per rotor varies from 2 to 6.
• More the number of lobes, higher the chances of less pulsating discharge.
• Bi-wing lobes offer wide sealing area and carry much volume compared to round tip.

Product Advantages:

• Easy maintenance.
• Minimum internal losses and excellent self - suction capabilities.
• Low power consumption and high volumetric efficiency.
• Robust Construction.
• Great CIP / SIP and anti-corrosive properties.
• Less numbers of moving parts.

Industry:

• Chemical
• Food & Beverages
• Pharmaceuticals
• Confectionary
• Dairy
• Cosmetics
• Sewage Industry.

Industry Sector:

• Food and dairy.
• Medical Sector
• Chemical Sector
• Waste Management

Product Application:

• Loading of oils and food products.
• Transferring food products such as cherries.
• Applicable for dyes and alcohols.
• Sewage applications.

Safety Measures:

Following points should be kept in mind as a safety measures while installing and running the pump:

• Read the instruction manual thoroughly.
• Do not run pump dry.
• All the guards and shields should be at their proper places before running.
• Make sure that the pump runs in assigned direction only.
• Check all the lubricants before installing.
• Pump casing should be filled with liquid.
• Do not use liquid other than that for which the pump is designed.
• Use proper strainers and filters to protect pump from abrasives.
• Pump and motor shaft alignment should be proper.
