Operational Features:

• As the single helical rotor rolls eccentrically in a double threaded helix stator of twice the pitch length, a series of sealed cavities 180° apart are created, that progress from suction to the discharge end. Thus, the opposing cavities fill and empty simultaneously, resulting in a pulsation free flow.
• The fluid travels axially with relatively low velocity and minimal agitation of the fluid, which makes this pump able to transfer the liquid without shear and churning action.
• If the fluid is delicate, shear sensitive or abrasive, low or high viscosity, with fibers, high air content, or large solids, our progressive cavity pumps can solve the problem of moving the fluid as they are versatile, rugged, compact and highly efficient.
• Our progressive cavity pumps are available in 1,2,3 and 4 stage design and each stage has a maximum pressure limit of 6 Bar.

Installation Features:

• Sealing Option: Gland Packing, Lip seal, Mechanical Seal, Seal less
• Bearing: External
• Mounting: Horizontally or vertically
• Direction of rotation: CCW(standard), CW(on request)
• Ports location: Radial inlet and axial outlet for standard rotation of direction
• Driving unit: Pump can be connected with the prime movers by means of flexible coupling or gear box or pulley drive
• Auxiliary systems: Dry run protection system, Flushing plan for seals
• The care must be taken that pumps are do not run dry.

Product Advantages:

• Solid drive design provides strength for rigorous continuous operation.
• Equal wall stator design available for some models which reduces pump slippage and increases pressure limit.
• Unique pivot-joint design extends service life and reduces replacement cost.
• Close coupled models with built on speed reducers offer a compact unit.
• Stators are available in a wide range of elastomers.
• Single, two, three and four stage models for pressure up to 24 Bar.
• Suction lift up to 28” water column.

Industry:

• Waste water and waste water treatment
• Chemical and petrochemical industry
• Paper and cellulose industry
• Soap and fats industry
• Paint and lacquer industry
• Food and beverage industry
• Plastics industry
• Ceramics industry
• Agriculture
• Sugar industry
• Shipbuilding

Industry Sector:

Product Application:

• Food and drink pumping
• Oil pumping
• Coal slurry pumping
• Sewage and sludge pumping
• Viscous chemical pumping
• Sewage and sludge pumping
• Shear sensitive products
• Pulp, paper paste and starch handling
• Biomass transfer
• Fluid dosing applications

Safety Measures:

Following points should be kept in mind as a safety measures while installing and running the pump:

• Read the instruction manual thoroughly.
• Do not run pump dry.
• All the guards and shields should be at their proper places before running.
• Make sure that the pump runs in assigned direction only.
• Check all the lubricants before installing.
• Pump casing should be filled with liquid.
• Do not use liquid other than that for which the pump is designed.
• Use proper strainers and filters to protect pump from abrasives.
