Trochoidal Gear Pumps

Download Catalogue

IL – 0X series is engineered to run at high speeds and have adaptability of mechanical seals for critical applications even for lower flows.

Product Reviews
Performance Table:
Pump Model Port Size Max Flow Max Pressure Speed Power
Inlet X Outlet (BSP) LPM Bar RPM KW
IL-01 ¼” X ¼” 4 3 1450 0.18
IL-02 ½” X ½” 10 6 1450 0.37
IL-03 ½” X ½” 15 6 1450 0.37
IL-04 ½” X ½” 20 6 1450 0.37
IL-05 1” X 1” 40 6 1450 0.75
IL-06 1 ½” X 1 ½” 80 6 1450 1.50
IL-08 1 ½” X 1 ½” 125 6 1450 2.23
IL-09 2” X 2” 150 6 1450 3.72
IL-10 2” X 2” 200 6 1450 3.72
IL-11 3” X 3” 250 6 960 5.60
IL-14 3” X 3” 300 6 960 5.60
Material of Construction Table:
Components Material Of Construction
Pump Casing and Covers Cast Iron
Rotor Set Sintered Iron / Cast Iron
Shaft Hardened Alloy Steel
Relief Valve Parts In spring steel and Cast Iron
...
...
